• 15"

• 3,000W max

• 1,700W RMS

• Blue, cast aluminum basket with diamond-cut accents

• Chrome back plate

• 2.5" dual 4ohm voice coils

• Overcompensating motor structure for increased magnetic strength

• 12mm T-yoke & top plate improve low-frequency dynamics

• Vented T-yoke & frame reduces voice-coil heat buildup

• Die-cast aluminum heat sink dust cap absorbs voice-coil heat

• Aluminum dust cap fins dissipate heat & strengthen cone

• Nonmagnetic nonresonant die-cast aluminum frame

• 4-layer voice coil with large gauge wire increases power

• High-temperature-tolerant adhesives resist thermal failure

• Nickel-plated, 8-gauge, spring-loaded compression wire terminals

• Nontransfer spruce pulp cone & high-density polyether foam surround with UV & chemical protection

• Dual poly-cotton suspension dampens violent accelerations

• Stitched voice coil leads prevent potential damage

• Efficiency: 86.97 @ 1W/1m

• Motor volume: 373oz

• Mounting depth: 8.125"

• Optimum sealed enclosure: 2 cu ft

• Optimum ported enclosure: 4 cu ft

• Includes 1-piece gasket/trim ring with concealed mounting holes
